Posiflex PS-3516 15.6" Widescreen POS Terminal

PS-3316-9_17062812434-PS-3316_copy-PS-3316E_copy_1

PS-3316-4_17062812833-PS-3316_copy-PS-3316E_copy_1

Overview

Crafted with functionality and flexibility in mind, The Posiflex PS-3516 Series features a 15.6” wide touch screen, fanless technology, and an adjustable base to scale to meet both retailers' and consumers' expectations—all within an affordable, yet attractive and feature-rich terminal.

Register to get started

Apply for a ForPOS account to view pricing, receive exclusive discounts and some other incentive etc etc.

My account

Key Features

15.6" TFT LCD 5-wire Resistive touch
Intel Apollo Lake N3350
Up to 8Gb RAM
64GB SSD as standard

Intelligently Designed

Equipped with an adjustable base, PS-3516 Series enables the ultimate flexibility for space-limited environments.

Expanded Capability

By separating a full set of ports into the top of the terminal, PS-3516 Series provides extensive connections, easy accessibility, and reliable peripheral cabling.

Durable

Powered by Intel® Apollo Lake N3350/J3455 processors, and constructed with a 15.6” resistive wide touchscreen, PS-3516 Series has the durability, style and power for the most challenging POS requirements.

System Configuration
Processor	Intel Apollo Lake N3350
System Memory	DDR3L SO-DIMM x 1, max. 8GB
Storage Device	M.2 connector (SATA Signal Only) x 1
Power Supply	12V/40W
OS Support	Windows 10 IoT

Display & Touch
LCD	15.6" TFT LCD
Resolution	1366 x 768
Touch	5-wire Resistive touch

I/O Expansion
Serial Port	4, DB9 x 3 + RJ50 x 1, 5V/12V support on all COM ports
Parallel Port	1, via optional conversion cable through service window
Standard USB Port	5, USB 3.0 x 2+ USB 2.0 x 2 (on I/O plate) + USB 2.0 x 1 (on the top)
PoweredUSB Port	Optional 24V x 1 + 12V x 3 via GEN8 base
OTG USB	N/A
LAN Port	10/100/1000 Mb x 1
Display Port	VGA x 1, 12V support for Posiflex monitors
CR Port	1, control 2 CR via optional Y-cable
PS/2 Port	1, via optional conversion cable through service window
Audio	Buzzer x 1; Optional internal 2W speaker x 1
Expansion Slot	M.2 slot x 1
